Single Diaphragm Large Size Engine IMPCO 425 Mixer

Name: Single Diaphragm Large Size Engine IMPCO 425 Mixer
Brand: IMPCO
Price: 1 USD

Brand Name : IMPCO

Model Number : Model 425

Certification : UL

Place of Origin : USA

MOQ : 24

Price : Depending on quantity

Payment Terms : T/T

Supply Ability : 1200pcs per 8weeks

Delivery Time : 8 weeks

Packaging Details : carton

Part Description : Carburetor

Fuel Type : LPG Vapor,Natural Gas

Diaphragm Material : Hydrin(Standard),Silicone(optional)

Mounting Position : Vertical

HP/KW Rating : 287 hp (214.0 kW)/ 333hp (248.0kW)

Flow Rate : 460 CFM (217.1 L/s)/ 533CFM(252.0L/s)

Contact Now

IMPCO Large Size Engine Carburetor Model 425 , Single-Diaphragm Air Valve , LPG Vapor / Natural Gas Applications

The Model 425 carburetor is a single-diaphragm air valve carburetor/mixer. It offers a down draft air inlet that can be used for remote air filtration or open-element type air filters. This unit is available for LPG Vapor and Natural Gas for applications requiring up to 460 CFM (217.1 L/s). The Model 425 is also available for feedback applications with the ‘FB’ designation. These FB mixers are available in a tamper resistant configuration, indicated by the “-CT” in the part number.

SPECIFICATIONS
Fuel Type	LPG Vapor, Natural Gas
Inlet Pressure	+8.0” w.c. (1.99 kPa) B5
Operating Temperature Range	-40ºF to +250ºF (-40ºC to 121ºC)
Mounting Position	Vertical
Diaphragm Material	Hydrin (Standard), Silicone (Optional)
HP/(kW) Rating	287 hp (214.0 kW) @ 460 CFM (217.1 L/s) and 1.5” Hg manifold depression 333 hp (248.0 kW) @ 533 CFM (252.0 L/s) and 2.0” Hg manifold depression
